The Process Engineering & Simulation Fundamentals of SRU & TGTU course hosted by Bryan Research & Engineering LLC will cover a detailed discussion of industrially relevant processes used in sulfur recovery and tail gas cleanup units. The operating principles of these units will be presented using plant representative simulation models, as well as an exploration of the rationale for common variations seen in these process units.
This one-day course will also cover the effective methods for process design, optimization, and troubleshooting. Its purpose is to provide participants with the information and understanding necessary to confidently make critical decisions regarding their own processes.
The course will begin by going through a straight-through basic Claus unit and understanding the importance and operation of each section of an SRU – acid gas burner, waste heat boiler, condensers, reheaters, hydrolyzing & general converters. Important plant indicators like overall sulfur recovery percentage, tail gas ratio, ammonia/hydrocarbon destruction, COS/CS2 formation and destruction etc., will also be discussed. It then transitions into exploring several different tail gas cleanup (TGCU) methods using case studies, comparing the resulting sulfur recoveries and the impact on plant SOx emissions. Next, a thorough discussion will be done on low pressure tail gas treating amine sweetening units and the reaction chemistry behind CO2 slip vs H2S pickup & recycle. The remaining time will introduce the concepts of heat exchanger rating and mass & heat flux calculations and the ability to utilize the power of process simulation for either controlling the performance of heat exchangers or designing / operating waste heat boilers.
Each attendee will go back with a technical manual specially prepared by the team at Bryan Research & Engineering LLC on plant design, optimization, and process simulation fundamentals of sulfur recovery.
A provisional agenda can be found here: https://www.bre.com/Sulfur-Recovery.aspx
